Location: Product=>Audio Guide System=>AG-600S |
User Data Analysis Audio Guide System AG-600S |
| ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
| |
◆ Main Feature of audio guide system
|
| ● Analyze user data of language, monthly, weekly, visiting time, attractions rank. |
|
|
| ● Built in speaker, 3.5mm stereo earphone jack output. |
| ● Yellow and blue dual color OLED screen, 128*64dot matrix. |
| ● Welcome screen can be customized. |
| ● Support audio files of Mp3 format, 8-48KHz sample rate, 8-320kbps bit rate and VBR. |
| ● 99 different languages can be selected ,4096 audio segments in each language. |
| ● Switch 99 different languages by wireless triggering. |
| ● Object name display, Support multi-language characters. |
| ● Numeric Keypad play function. |
|
| ● Can be triggered by passive tag within 0-5cm. |
|
| ● Can be triggered by infrared ray within 0-10m. |
|
|
| ● Can be triggered by RF signal within 0-100m. |
|
| ● With volume control function, maximum output volume can be locked. |
 |
| ● With play restrict and play times statistics functions, apply to rental. |
| ● With play, pause, fast forward, rewind functions. |
| ● With replaying function, the latest three triggered contents can be replayed. |
| ● Auto playing background music when trigger playing ended. |
|
| ● Can vibrate and buzz when triggering. |
| ● With anti-theft alarm function. |
| ● With Audio-video Synchronization function. |
| ● Battery level of RFID trigger and IRT-6 trigger can be shown on Audio Guide. |
|
| ● Charger adopts 2U rack-mounted design to be installed in 19-inch standard cabinet. |
|
| ● High capacity lithium-ion battery, continuous operating time is more than 12 hours. |
|
| ● Parameters only can be changed by wireless decoder, prevent guests from amending parameters. |
| ● Special upload software convenient to update audio contents. |
 |
| ● Extra audio files control function. |
| ● 224 users data can be stored in AG-600S, no need to export the user data every day. |
| ● The exported user data can be uploaded to the computer by wireless transmission. |
| ● The charger can export user data while charging. |
| ● One computer can be wirelessly connected to 256 chargers, it can export the user data of |
| 3072 audio guide units at one time. |
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
| |
◆ Select multi-languages |
| |
|
|
|
|
|
|
|
| |
|
| |
| |
|
|
|
|
|
 |
| |
| |
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
| |
◆ Intelligent Triggering |
| |
Passive Tag L45A |
Infrared Trigger IRT-6 |
RFID Trigger RFT-6 |
|
| |
Activate range:0～5cm |
Activate range:0～10m,4 steps adj |
Activate range:0～100m,16 steps adj |
|
| |
NO power supply |
Battery:AA alkaline battery 1.5V*2 |
Battery:AA alkaline battery 1.5V*2 |
|
| |
|
Battery life:>15 months (measured) |
Battery life:>3 years (measured) |
|
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
| |
◆ Realization of video synchronization |
| |
|
|
|
|
|
| |
| Direct trigger: |
| When visitors bringing the smart |
| audio guide device into the trigger |
| area, the device can automatically |
| play the audio that is synchronized |
| the video screen. |
| |
| Indirect trigger: |
| When visitors bringing the smart |
| audio guide device into the trigger |
| area, the device must trigger the |
| audio file of current playing video |
| first, then can automatically play the |
| audio that is synchronized with the |
| video screen. |
|
| |
| ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
| |
◆ Welcome screen customization |
|
| |
| |
● Welcome display screen could show any character, pattern, logo, etc. |
| |
● And welcome display can be edited by user own.
|
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
◆ User data export and charging |
|
| |
1.User data is imported into the computer wirelessly. |
|
| |
2.Export the user data while charging, audio guide device automatically turn on when exporting the user data, and |
|
| |
automatically turn off after exporting completed. |
|
| |
3.Data export host UD-Master can automatically paired connected to 256 data export charger UD-12B, user data of |
|
| |
3072 audio guide device can be exported, each audio guide device can stores 224 users’ data, it can import more |
|
| |
than 680,000 visitors’ data at one time.
|
|
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
|
| ◆ Data export analysis software S-Analyst |
|
|
| |
|
|
|
|
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
◆ System Specification of audio guide system |
| |
Ways of play |
Keypad playing & smart trigger playing |
|
|
RF Trigger |
2.4GHz / 0～100m trigger range (16 levels adjustable) |
|
|
Infrared Ray Trigger |
38KHz / 0～10m trigger range (4 levels adjustable) |
|
| Passive Tag Trigger |
13.56MHz / 14443A standard (0～5cm trigger range) |
|
| |
File Format |
Mp3 Format (8-48KHz sample rates, 8-320kbps bitrate) |
|
| Memory Capacity |
8GB |
|
| |
Data Export Content |
Used language,visited scenic spots,visiting time |
|
| |
User Data Storage |
224 user data |
|
| |
Multi-Language |
99 |
|
| |
Tracks Number |
4096 (per language) |
|
| |
Display name of object |
Support multi-language text display |
|
| |
Built in speaker |
8Ω/0.5w |
|
| |
Earphone Output |
3.5mm stereo |
|
| |
Volume Control |
32 levels electronic volume control |
|
| |
Play controls |
Previous/Next, Fast forward/Rewind, Play/Pause |
|
| |
Audio Frequency Response |
50～18,000Hz |
|
| |
Distortion |
<0.02% |
|
| |
Audio Dynamic Range |
88dB |
|
| |
S/N Ratio |
96dB |
|
| |
Operating Temperature |
-10～60℃ |
|
| |
Power Supply |
Built-in Lithium ion battery 3.7v/1020mAh |
|
| |
Operating Time |
About 12 hours |
|
| |
Dimension |
108*49*16mm |
|
| Weight |
65g (include battery) |
|
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ |
| |
◆ Optional Accessories of audio guide system |
| |
 |
|
 |
|
 |
|
 |
|
 |
|
|
RFT-6 |
|
IRT-6 |
|
L45A / B |
|
K96 |
|
EW100 |
|
|
RFID Trigger |
|
Infrared Trigger |
|
Passive Tag |
|
Display Card |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
| |
 |
|
 |
|
 |
|
 |
|
 |
|
|
WD-600 |
|
AVT-8 |
|
SC-02B |
|
SC-12B / SU-12B |
|
SCB-24BD |
|
|
Wireless Decoder |
|
Audio-Video Trigger
|
|
2-Slots Charger |
|
12-Slots Charger/
|
|
24-Slots Charging/ |
|
| 12-Slots Uploader |
Disinfection Case |
|
|
